Feature
Technical Specifications
|
|
MJ90 |
MJ45 |
|
Dimension of sliding table |
2800*310mm |
3000*375mm |
|
Max cutting length |
2800mm |
3000mm |
|
Max lengthways cutting |
1250mm |
900mm |
|
Cutter blade specification |
300mm |
300mm |
|
Diameter of guide shaft spindle |
4000/6000rpm |
4000/6000rpm |
|
Main spindle diameter |
30mm |
30mm |
|
Tilting saw bladle |
0-90° |
0-45° |
|
Main motor power |
4kw |
4kw |
|
Scoring motor power |
0.75kw |
0.75kw |
|
Machine size |
2800*2550*900mm |
3050*3150*900mm |
|
Net weight |
600kg |
700kg |
Application
FAQ
FAQ
what is the advantage of the front loading computer beam saw?
make the worker feed the panel more easily.
