Feature
This machine is used for wrapping the veneer, PVC,CPL,PE,paper,etc materials on plastic profile and other skirting boards, door frame,jamb,L-architrave, and railings of stairs. The wrapping of surface, sides and bottom are accomplished in a single process.
Technical Specifications
Exterior size:6000mm×800 mm×2150mm
Gluing way:Coating PUR hot glue
Maxi gluing width：30-330mm
Maximum height of the work piece:165mm
Maximum length of the work piece:400mm〜Unlimited
Speed of working:0〜35m/Min
Expansion shaft diameter: Φ71mm, with brake.
Glue melter:5 Gallon drum
Power consumption :about 12-16Kw
Weight :3.5T
All the material(PVC,veneer) should be rolls
If wrapping the veneer(back with non-woven fabric) or CPL(melamine paper),based on the round corner ,the radian of corner is more than R3,because veneer and CPL have no elastic, especially the CPL is very hard and crisp.
If more than 10 days not work, please clean up the glue melter,glue hose,slot nozzle gun using the PUR cleaning agent or EVA,and seal them to isolate from air.
