Feature
LM-960 is an high-speed linear edge banding machine. Heavy-duty track transmission ensures a more stable processing procedure. Touchscreen intelligent control, with a processing speed of up to 15m/min. All components are made of good brand products, with excellent assembly to ensure the stability of the equipment. It can adapt to production and operation in high and low temperature climates and other harsh environments. This equipment features good stability, high efficiency, precise processing and convenient operation.
Technical Specifications
| Equipment model | LM-960 | Thickness of panel (mm) | 18-25 |
| Overall dimensions (cm) | 8.82*1.07*1.85 | Machining shape | straight |
| Total weight T | 3.72 | Thickness of edge banding(mm) | 1.2 |
| Total power(kw) | 22.3 | Edge banding width(mm) | 22-29 |
| Voltage | 380 | Minimum sheet width(mm) | ≥100 |
| Pressure(mp) | 0.6-0.8 | Minimum sheet length(mm) | ≥100 |
| Suction inlet(mm) | Ф100*4 | Conveying speed(m/min) | 8-15 |
