Feature
Features：
1. Function：Edge press+belt cut+end cut+fine trim+scraper+buffing+grooving. ZHF202C adds scrapping and grooving functions. Bettered the edge trimming performance.
2. Suitable for pvc,melamine and thin batten edge band work
Technical Specifications
Parameter：
|
Panel length |
≥120mm |
|
Panel width |
≥60mm |
|
Panel thickness |
10-50mm |
|
Belt thickness |
1-3mm |
|
Feeding speed |
10mm/min |
|
Input voltage |
380V-50HZ |
|
Pneumatic pressure |
0.6MPa |
|
Total power |
7Kw |
|
Suction inlet dia. |
100mm |
|
Machine size |
48100x800x1450mm |
|
Machine weight |
1800Kg |
Application
FAQ
FAQ
How many square meters does the whole line cover?
The whole line covers an area of 162 square meters (27X6 meters)
Can choose other model of double side edge banding machine ?
yes , we can do as your requiry functions
