Feature
1. function：edge press+belt cut+end cut+fine trimming+scrapper+buffing. ZHF202E adds scrapping function. Bettered the edge trimming performance.
2. Suitable for PVC, Melamine and thin batten edge band work
Technical Specifications
Parameter：
|
Panel length |
≥120mm |
|
Panel width |
≥60mm |
|
Panel thickness |
10-50mm |
|
Belt thickness |
1-3mm |
|
Feeding speed |
10mm/min |
|
Input voltage |
380V-50HZ |
|
Pneumatic pressure |
0.6MPa |
|
Total power |
4Kw |
|
Suction inlet dia. |
100mm |
|
Machine size |
3800x800x1450mm |
|
Machine weight |
1600Kg |
