MJ90 | MJ45 | |
Dimension of sliding table | 2800*310mm | 3000*375mm |
Max cutting length | 2800mm | 3000mm |
Max lengthways cutting | 1250mm | 900mm |
Cutter blade specification | 300mm | 300mm |
Diameter of guide shaft spindle | 4000/6000rpm | 4000/6000rpm |
Main spindle diameter | 30mm | 30mm |
Tilting saw bladle | 0-90° | 0-45° |
Main motor power | 4kw | 4kw |
Scoring motor power | 0.75kw | 0.75kw |
Machine size | 2800*2550*900mm | 3050*3150*900mm |
Net weight | 600kg | 700kg |
