Main Characteristic
High motion accuracy；Instead of pulse communications，servo motor use digital communications for ensuring data accuracy.
High configuration system; German BECKHOFF Control system guarantees the reliability and stability of daily operation, and also expedites the different software application adopting.
Cooperate with mainstream software; the application software is highly matched with Yuanfang software.
Technical Parameter
Model | MJ6225Z | MJ6232Z | MJ6238Z |
Max cutting size | 2500mm | 3200mm | 3800mm |
Max cutting thickness | 105mm | 105mm | 105mm |
Max cutting speed | 1-75m/min | 1-75m/min | 1-75m/min |
Max feeding speed | 1-45m/min | 1-45m/min | 1-45m/min |
Overall size | 5690X5290X2130mm | 6390X5990X2130mm | 6990X6590X2130mm |
N/W | 3900Kg | 4500Kg | 5100Kg |
