Main characteristic：
The edge banding materials include PVC, Melamine and thin batten etc.
The high-speed CNC control system automatic monitoring and displaying the whole processes on the touch screen, such as malfunction.
High-power and speed motors with high-quality knives doubles the work.
Advanced frame of product and powerful functions combination, easily use and adjust.
The Humanity Operating system include frequency-conversion feeding, crossbeam up-and-down by electromotion, full-close safety shield.
High feeding speed and excellent trimming effectiveness result in high yield during massive production.
Technical parameter：
Model | MDZ515A | MDZ515B |
Panel width | ≥80mm | ≥80mm |
Panel thickness | 8-50mm | 8-50mm |
Edge thickness | 0.4-3mm | 0.4-3mm |
Feed speed | 12-20m/min | 12-20m/min |
Power | 18.14KW | 16.54KW |
Pneumatic power | ≥6Kg/cm2 | ≥6Kg/cm2 |
Overall size | 8180X770X1590mm | 7580X770X1590mm |
