Main Characteristic
Progressive touch screen、PLC control system, multi-function and low failure rate;
Large scope of Drilling, convenient and efficient driller installation;
Digital display shows the drill depth and distance, to ensure the accuracy of the size;
All drill bits equipped pneumatic system with adjustable locking.
High speed feeding system, rotate steadily and high working efficiency
Steadily frame instruction, steadily, has emergency stop system to guarantee the safety.
Technical Parameter
Model | BJK172A | |
Distance between the bit | 32mm | |
Drill chuck QTY | Horizontal | 2 |
Vertical | 5X2=10 | |
Quantity of bits | 152 | |
Max boring diameter | φ35mm | |
Max panel thickness | 60mm | |
Max panel width | 2450mm | |
Min panel width | 250mm | |
Feeding speed | 57m/min | |
TOTAL POWER | 12.55Kw | |
Diameter of suction port | 100mmx6 | |
Pneumatic power | 0.6-0.8Mpa | |
Machine size | 3950X1800X1600mm | |
Net weight | 2800Kg | |
