Main Characteristic
Horizontal drilling group can revolve 90°,pneumatically controlled, drilling special drilling angles are available;
Technical Parameter
Model | BJK21A | BJK21B |
Distance between the bit | 32mm | 32mm |
Quantity of bits | 21 | 21 |
Max boring diameter | ￠35mm | ￠35mm |
Max panel thickness | 60mm | 60mm |
Power | 1.5Kw 380V 50Hz | 1.5Kw 380V 50Hz |
Pneumatic power | 0.6Mpa | 0.6Mpa |
Machine size(L*W*H) | 1250×1250×1300mm | 2400×1000×1120mm |
Net weight | 350kg | 300kg |
