Working length | 1800～2500mm |
Working width | 300～1100mm |
Working thickness | 30～65mm |
Main saw motor power | 2 x11Kw（vertical） 2*7.5Kw （horizontal） |
Main saw blade dia. | D300mm-d30mm |
Main saw blade max speed | 6000rpm |
Secondary saw blade dia. | D80mm-d22mm |
Secondary saw blade max speed | 6000rpm |
Secondary saw blade motor power | 4x1.1 Kw |
servo motor power | 3x1.0 Kw |
Vacuum pump | 2*7.5 kw |
Conveyor belt power | 2x0.75 Kw |
Conveyor belt height | 925mm |
Voltage | Three phase 5 wire 380V 60HZ |
Total power | 69.9KW |
Suction inlet dia | 100mm*7 |
Pneumatic pressure | 0.5～0.7MPa |
Machine dimension | 4900X2500X2300 mm |
Machine Weight | 4500 Kg |
1. The four saw sets are equipped with main and scoring saws working together ensures the clean cutting surfaces and edges. 2.The two vertical edge saw sets are setting under the workpiece. As the thickness of the wooden door changes, the height of scoring saws does not need to be adjusted. 3.The vertical edge is centered for sawing. Two vertical edges saw group Angle may adjust the 0 ~ 6 °. 4.The longitudinal automatic feeding and unloading system can add the bar code scanning according to the needs of the automatic production line.
5.The strong adsorption capacity vacuum table with the self-adaptive magnetic scale 6.Automatic lubrication system, parametric programming consists the user friendly HMI interface. | |
